Contrast ratio of NEC MultiSync 20WGX2

Contrast ratio 376:1 (edge: 484:1)
Monitor model NEC MultiSync 20WGX2
Submitted 13 Jan 2012 22:17 CET, by 217.118.*.*
Camera model Panasonic DMC-TZ7
Processing remarks

Note: image file 1: suggested exposure time: 1.8 s (Set EV to +0.9)
Note: image file 2: suggested exposure time: 1/200 s (Set EV to -3.0)
Note: image file 3: suggested exposure time: 2.4 s (Set EV to +0.9)

Black
Screen photo
[open image]
Luminance 0.22 cd/m2
Luminance spread 0.08 cd/m2 (2 standard deviations)
Exposure value –3.71 stops   (aim for –2 to –3)
Exposure spread 0.5 stops
Area used for calculation 0.361 x 0.361
Camera settings Exposure time: 0.8   ISO: 400   F-number: 3.3
Focal length: 25 mm   (35 mm equivalent)
Exposure compensation: -0.33
White
Screen photo
[open image]
Luminance 84 cd/m2
Luminance spread 7 cd/m2 (2 standard deviations)
Exposure value –1.47 stops   (aim for –2 to –3)
Exposure spread 0.12 stops
Area used for calculation 0.448 x 0.448
Camera settings Exposure time: 1/100   ISO: 400   F-number: 3.3
Focal length: 31 mm   (35 mm equivalent)
Exposure compensation: -2
Black at screen edge
Screen photo
[open image]
Luminance 0.17 cd/m2
Luminance spread 0.04 cd/m2 (2 standard deviations)
Exposure value –3.75 stops   (aim for –2 to –3)
Exposure spread 0.34 stops
Area used for calculation 0.361 x 0.361
Camera settings Exposure time: 1   ISO: 400   F-number: 3.3
Focal length: 25 mm   (35 mm equivalent)
Exposure compensation: -0.33

The luminance values in cd/m2 are not very reliable, since camera sensitivities can easily differ up to 50% from their nominal value. Typically, the real luminance is 30% lower than this number. The area used for calculation is chosen such that it corresponds to a viewing angle of ±14° horizontally and ±10.5° vertically, which is equivalent to viewing the screen from a distance of about 1.5 times the diagonal size.

Unfortunately, there is a lot of variation in how cameras use EXIF settings. If photos from your camera your produce unusable results, try coming back in a few days. I review submitted pictures regularly and try to fix problems.
